Mounting type

Lock screw / paste

Connector type

Double Cabel RG174 , SMA-J / FAKRA-C / FAKRA-D

Dimensions (mm)

φ80 x 15(H)

Operating temperature

-40°C to +85°C

Antenna and electrical specifications

Standards

GPS/GNSS/BD/4G

Frequency (MHz)

1559 , 1575 , 1602 , 1710~2690

VSWR

2.8 , 3.5 , 2.5 , <3.5

Peak Gain (dBi)

30±1 , 2.0~3.5

Impendance (Ohm)

50

Max Input Power (W)

5
